Signamax KJS458MT-C6AC MT-Series CAT6A Screened Keystone Jacks

KJS458MT-C6AC|47-KJS458MT6

Signamax KJS458MT-C6AC MT-Series CAT6A Screened Keystone Jacks

KJS458MT-C6AC|47-KJS458MT6

Se connecter prix revendeur

Devenir client ADI
Image of 47-KJS458MT6
Signamax

Signamax KJS458MT-C6AC MT-Series CAT6A Screened Keystone Jacks

KJS458MT-C6AC | 47-KJS458MT6

Veuillez vous connecter pour voir les tarifs, consulter la disponibilité des produits et ajouter des articles à votre panier.

Aperçu
Spécifications
Documents

Aperçu

The Signamax Category 6A Screened MT-Series Keystone Jacks have been designed to meet the need for today's high-bandwidth applications. These connectors are slim in profile for the highest-density applications and have the ability to mount either color-coded icons for service identification or dust covers to protect unused jacks from dust and other contaminants. Special design features allow these jacks to be terminated with a standard 110 single-position tool or with the Signamax four-pair tool. The contact design provides enhanced plug-to-jack connection integrity, protects against damage caused by insertion of 4- or 6-position plugs, and is rated for a minimum of 750 plug insertions providing for the highest level of system reliability.

Principales caractéristiques

  • Exceed ANSI/TIA-568-C.2 component performance specifications
  • Meet IEEE 802.3an 10 Gigabit Ethernet transmission requirements
  • Overall solid-metal shielding design for 360-degree screen coverage
  • Compatible with Signamax screened snap-in patch panels and work area faceplates
  • Improved wire retention and ease of termination with rear 110 type contacts
  • Easy-to-read T568A/B wiring scheme color-code label
  • Circuit identification icons and dust covers included in kit
  • Renseignements généraux

    Name: Signamax KJS458MT-C6AC MT-Series CAT6A Screened Keystone Jacks
    Category:
    UPC Code: 763474170784
    Country of Origin: Taiwan, Province of China. Country of origin is subject to change.
