Image of 6E-DA11XLR
Blustream

Blustream DA11XLR Analogue XLR Audio to Dante Encoder

DA11XLR|6E-DA11XLR
Blustream

Blustream DA11XLR Analogue XLR Audio to Dante Encoder

DA11XLR|6E-DA11XLR

Sign In for Dealer Pricing

Become an ADI Customer
Image of 6E-DA11XLR
Blustream

Blustream DA11XLR Analogue XLR Audio to Dante Encoder

DA11XLR | 6E-DA11XLR

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

The DA11XLR is a multi-input XLR to Dante networked audio system. The DA11XLR converts 2 input channels of balanced / unbalanced / MIC audio with switchable 48V Phantom power to Dante digital audio. The DA11XLR is a plug and play device that is powered using PoE (Power over Ethernet), or via 12V power supply, offers support for AES67 RTP audio transport.

Main Features

  • Dante network interface for 2 x XLR audio inputs
  • Converts 2 x balanced / unbalanced / MIC audio sources to Dante audio channels
  • Switchable 48V Phantom power for each MIC XLR input
  • Adjustable MIC / line sensitivity from +24dBu to -28dBV for each XLR input
  • Supports- 441, 48, 882 and 96 KHz sample rates at 16, 24 and 32 Bit
  • Configurable Dante device latency (supports 2, 3, 4, 5 or 10ms configurable using Dante Controller)
  • Supports AES67 RTP audio transport
  • Features Class 0 8023af PoE for powering of product from any PoE switch
  • In-built web-GUI for configuration and control
  • Local 12V power supply input for when network switch does not support PoE

    • General Information

    Name: Blustream DA11XLR Analogue XLR Audio to Dante Encoder
    Category:
    UPC Code: 934024200538
    Country of Origin: . Country of origin is subject to change.

    Specifications

    Product Documents and Resources

    Product Data Sheet
