Altronix EFLOW4NA8V Access Power Controller with Power Supply / Charger, Includes BC400 Enclosure, 8-Fused Relay Outputs, 12/24VDC, 4A, Aux Output, FAI, 220VAC
EFLOW4NA8V|AX-EFLOWNA8V
Altronix EFLOW4NA8V Access Power Controller with Power Supply / Charger, Includes BC400 Enclosure, 8-Fused Relay Outputs, 12/24VDC, 4A, Aux Output, FAI, 220VAC
EFLOW4NA8V|AX-EFLOWNA8V
Altronix
Altronix EFLOW4NA8V Access Power Controller with Power Supply / Charger, Includes BC400 Enclosure, 8-Fused Relay Outputs, 12/24VDC, 4A, Aux Output, FAI, 220VAC
EFLOW4NA8V | AX-EFLOWNA8V
Veuillez vous connecter pour voir les tarifs, consulter la disponibilité des produits et ajouter des articles à votre panier.
Aperçu
Spécifications
Documents
Aperçu
Introducing the Altronix EFLOW4NA8V Access Power Controller, designed to efficiently manage power for your access control systems and accessories. This robust unit transforms a 220V AC input into eight independently controlled, fuse-protected outputs, delivering a total of 4A continuous supply current at either 12V DC or 24V DC. With versatile activation options, it seamlessly integrates with various access control devices such as mag locks and electric strikes, operating in both fail-safe and fail-secure modes. The FACP interface supports emergency egress and alarm monitoring, ensuring safety and reliability. Upgrade your security system today with the Altronix EFLOW4NA8V!
Principales caractéristiques
Renseignements généraux
Name: Altronix EFLOW4NA8V Access Power Controller with Power Supply / Charger, Includes BC400 Enclosure, 8-Fused Relay Outputs, 12/24VDC, 4A, Aux Output, FAI, 220VAC
Category:
UPC Code:
Country of Origin: . Country of origin is subject to change.
Spécifications
ADI Numéro du produit AX-EFLOWNA8V Code fabricant EFLOW4NA8V Fabricant Altronix Corporation Gamme eFlow102N Genre du connecteur Access Control Marque Altronix Modèle de produit EFLOW4NA8V Nom de produit Access Power Controller With Power Supply/Charger, 8 Fused Relay Outputs, 12/24VDC, 4A, Aux Output, FAI, 220VAC, BC400 Enclosure Type de produit Access Power Controller
Nombre de porte(s) 8 Tension de sortie 12V DC, 24V DC
NDAA Compliant Yes
Température de fonctionnement 32-120°F Temperature de stockage (T-T) -4-158°F
Hauteur 16" Largeur 12" Poids 8.65lb Profondeur 4.5"
Tension d'entrée 220V AC
Garantie Limitée Lifetime
Caractéristiques AC fail supervision (form "C" contacts), Alarm output relay indicates that FACP input is triggered (form "C" contact rated @ 1A 28VDC not evaluated by UL), Automatic switch over to stand-by battery when AC fails. Transfer to stand-by battery power is instantaneous with no interruption, Battery fail & presence supervision (form "C" contacts), Built-in charger for sealed lead acid or gel type batteries, Fire Alarm disconnect (latching or non-latching) is individually selectable for any or all of the eight (8) outputs, Low power shutdown. Shuts down DC output terminals if battery voltage drops below 71-73% for 12V units and 70-75% for 24V units (depending on the power supply). Prevents deep battery discharge, Normally open (NO) or normally closed (NC) dry contact input, Polarity reversal input from FACP signaling circuit, Zero voltage drop when unit switches over to battery backup (AC failure condition) Certification environnementale RoHS
