Image of TC-PDU3EVN6L
Acheter Eaton Tripp Lite

Eaton Tripp Lite PDU3EVN6L2130 45-Outlet Monitored PDU with LX Interface, Gigabit, L21-30P Input, LCD, 8.6kW, 208/120V, 3PH, 0U, 1.8m Height, 1.8m Cord

PDU3EVN6L2130|TC-PDU3EVN6L
Acheter Eaton Tripp Lite

Eaton Tripp Lite PDU3EVN6L2130 45-Outlet Monitored PDU with LX Interface, Gigabit, L21-30P Input, LCD, 8.6kW, 208/120V, 3PH, 0U, 1.8m Height, 1.8m Cord

PDU3EVN6L2130|TC-PDU3EVN6L

Se connecter prix revendeur

Devenir client ADI
Image of TC-PDU3EVN6L
Eaton Tripp Lite

Eaton Tripp Lite PDU3EVN6L2130 45-Outlet Monitored PDU with LX Interface, Gigabit, L21-30P Input, LCD, 8.6kW, 208/120V, 3PH, 0U, 1.8m Height, 1.8m Cord

PDU3EVN6L2130 | TC-PDU3EVN6L

Veuillez vous connecter pour voir les tarifs, consulter la disponibilité des produits et ajouter des articles à votre panier.

Aperçu
Spécifications
Documents

Aperçu

The PDU3EVN6L2130 8.6kW 3-Phase Monitored PDU provides real-time remote monitoring of voltage, frequency and load levels via built-in network connection. Recommended for IT and industrial applications, it features 45 outlets—36 C13 (208V), 6 C19 (208V) and 3 NEMA 5-15/20R (120V)—with included plug-lock insert sleeves to prevent cables from becoming accidentally disconnected. A 6' (1.83m) cord with NEMA L21-30P input plug connects the 3-phase PDU to a compatible AC power source, generator or protected UPS. The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and NTP. A color touchscreen LCD lets you toggle between menus to monitor input current level per phase and output current per load bank with ±1% billing-grade accuracy, environmental sensor data and network information. It also generates a unique QR code to allow access to the PDU through a mobile device. The 0U PDU mounts vertically in racks using the included toolless mounting buttons or the included rack-mounting brackets. Use the included PDUMVROTATEBRKT kit to install the unit with outlets facing the rear for better airflow or equipment access.

Principales caractéristiques

  • 8.6kW 3-Phase Monitored PDU
  • Real-time remote monitoring via network
  • 45 outlets with plug-lock sleeves
  • Six-foot cord with NEMA L21-30P input
  • Java-free HTML5-based LX Platform
  • Supports multiple network protocols
  • Color touchscreen LCD with ±1% accuracy
  • Vertical 0U rack mounting
  • Optional environmental monitoring
  • Optional EnviroSense2 modules for environmental monitoring

    • Renseignements généraux

    Name: Eaton Tripp Lite PDU3EVN6L2130 45-Outlet Monitored PDU with LX Interface, Gigabit, L21-30P Input, LCD, 8.6kW, 208/120V, 3PH, 0U, 1.8m Height, 1.8m Cord
    Category:
    UPC Code: 037332195364
    Country of Origin: . Country of origin is subject to change.

    Spécifications
